MPPT, LCD display，RS485, 12/24V system voltage
- Innovative Max Power Point Tracking(MPPT) technology, tracking efficiency >99.9%
- Full digital technology, high charge conversion efficiency up to 98%
- Real-time energy statistics function.
- AGM, Liquid and GEL battery for selection
- Four stages charge way: MPPT, boost, equalization, float
- With current-limiting charging mode, when the power of solar panel is over-sized and charging current exceeds the
- rated current, the controller will lower the charging power, which enables the system to work under the rated charging current
- Multiple load control modes: Standard, Dusk to Dawn, Timer, and User-defined mode.
- Based RS-485 standard Modbus protocol, to maximize their communication needs of different occasions.
- Full automatic electronic protect function
- LCD display design, read operating data and working conditions easily.
- 12V/24V automatic recognition
- Perfect EMC & thermal design
- External temperature sensor, automatic temperature compensation
- Built-in temperature sensor, when the temperature exceeds the set value, the charging current will lower down followed by the decrease of temperature, so as to control the controller’s temperature rise
