Specifications:

– Output Power: 5 Watts (CB), 15 Watt (LMR)
– CB Channels: 2 Banks: 80(CB), 19 (LMR – Dealer Programmable)
– CB Frequency Range: 476.425 ~ 477.4125MHz
– LMR Frequency Range: 450 ~ 520MHz
– Channel Width: 12.5kHz (Narrowband + Wideband))
– Power Source (Nominal): 13.8V
– Max Absorption Current in TX: 1.3A (5W), <3.2A (15W)
– Operation Mode: Simplex & Duplex
– Audio Output Power: 4 Watt (Base & Microphone)
– Digital Coded Squelch (DCS): 104
– Interference Eliminator (CTCSS): 50
– Duplex Capability: Yes
– Channel Memory Scan: Yes
– Scan/Priority Scan: Yes
– Backlit LCD Display: Yes, 7 Colour (Selectable)
– External Speaker Jack: Yes
– TX/RX Indicator: Yes
– Scanning Receive Functions: Yes
– Key Lock: Yes
– Key Beep On/Off: Yes
– Auto Squelch: Yes
– Speaker: Dual (Base & Microphone)
– USB Charging Port: Yes
– Typical Range: 18km Line of Sight
– Slide-In Mounting Cradle: Yes
– Dimensions: (excl bracket) 110H x 120W x 25D mm

Antenna:

– 4dB
– 60cm Mast
– Commercial Grade LMR 240 Low Loss Coax 5m
